Πλήρης αυτόματος εκτυπωτής σέρβις

4 colors servo pad printer with servo working table//Usage and characters

• Configure shuttle table, servo motor drive, high precision, can be up and down, back and forth, left and right to adjust the angle of rotation.
• Shuttle stroke 200m, for the dimensions of 250 × 300mm printing products, the relative position between the respective printing colors can be flexibly adjusted.
• Oil cup for ink, ink saving more ink suitable stability, better environmental protection; 86% reduction in solvent evaporation, ink save 25% more business through the ISO14001 environmental management system certification;
• Automatic pad cleaning device in the pad printing process, plastic head surface residual ink can be self-cleaning, to avoid the influence of the first printing. Effectively improve the print quality;
• Independent oil cup propelling mechanism, wiper cleaner, safety design, ensure the operation more humane, scraping scraping under pressure to ensure a clean minimal, maximize oil cup and plate life;
• Thin and thick sheets double structure design, the user can choose according to their needs.
• Plastic cylinder head and the platen is controlled by a separate printing color between the mutual non-interference; can achieve multicolor printing large objects, tune more convenient;

Application fields

   Electrons, hardware, autos, toys, gifts, Plastics, household appliances, artwork, stationery, adornment, cosmetic, commodity, sport goods, decorative lightings, woodwork, office supplies, Photo Materials, Kitchen utensils, Hotel supplies, Computer, Mobile, etc., industrial field.

4 colors servo pad printer with shuttle//Parameter

• Max. plate size: 100×250mm.
• Max. worktable area: 165×200mm.
• Sealed cup diameter: Φ90mm
• Max. printing speed: 850pcs/h.
• Printable color: 4
• Shuttle stroke:125mm.
• Max print area: 80×170mm.
• Works supply: 110V-220V Power supply;5-7Bar Compress air;
• Package dimension: 1.260×0.810×1.520m
• Gross weight: 235KG.
• CBM: 1.63246
• H.S.Code :8443198000
• Certicate: CE
